Product Features:

Intel Pentium®4 Processor (Prescott)
Socket 775 with FSB 533/800 MHz
2 DDR 333/400 Memory Sockets ( Dual Channel)
1*PCI Express x 16, 1*PCI Express x 1, 2*PCI Slots
6 Channel AC97 Audio, Realtek 10/100 Ethernet LAN
4 Serial ATA150 Channels,
Integrated 3D Graphics Engine (Share memory maximum 8 MB)
8 USB 2.0/1.1 Ports (4 ports by optional cable)

Product Specification:

Processor

Socket 775 Intel Pentium®4 Processor (Prescott)

FSB

533/800 MHz

Chipset

North Bridge : Intel 915G (Grantsdale G)
South Bridge : Intel ICH6
LAN Chip : Realtek RTL8100C 10/100 Ethernet LAN
AC97 Audio Codec : Realtek ALC655
I/O Chip: Winbond Smart I/O W83627THF

Memory

2 * DDR Sockets:
DDR333/400 NON-ECC DDR SDRAM up to 2GB (Dual Channel)

Expansion Slots

1 x PCI Express x 16
1 x PCI Express x 1
2 x PCI slots (PCI 2.3 compliant)

IDE / SATA Connectors

1* ATA100 Channel, up to 2 ATA 100 IDE devices

Onboard I/O Connectors

1 x Floppy Connector
2 x USB 2.0/1.1 header (4 ports by optional cable)
1 x CD_IN header
1 x S/PDIF in/out header (S/PDIF in/out cable optional)
1 x CPU fan header ( 1 fan rotation detection function )
2 x System fan headers ( 2 fan rotation detection function )
1 x 10 pin system panel header (Intel spec)
1 x 3 pin Power LED header
1 x Front audio header (Intel spec)
1 x IrDA header
1 x Case Open detection header

I/O via Back Panel

PS/2 keyboard/mouse, 4 x USB(2.0/1.1), 1x RJ45 ,1 x Com(serial), 1 x Parallel, 1xLine-in/Line-out(Speaker Out)/MIC

Power

24-pin ATX power connector, 4-pin ATX 12V power connector

BIOS Feature

4Mb Flash EEPROM
Award BIOS with ACPI, DMI2.0, PnP, WfM2.0, Green Suspend to RAM (S3), Suspend to Disk (S4) Wake on keyboard/mouse, Wake on LAN/RTC Timer

Hardware Monitoring

3 FAN sensors, CPU/System voltages and temperature monitoring

Special Feature

Zero Jumper Design
Adjustable CPU frequency by 1 MHz increment, Adjustable Vcore , VAGP , VMemory for overclocking
Watch Dog Timer (auto-reset system when it can not handle overclock configurations)

Certifications

FCC, CE, BSMI

Form Factor

Micro-ATX (229mm x 244mm)
