Fractal Design Define R5 Mid Tower Case - Black

Customer rating

Click to share your rating 7 ratings (5.0/5.0 average) Thanks for your vote!

Share this product

$234.00
or 4 payments of $58.50 with Learn more
Hurry! Only 1 left at Mighty Ape!

The item is brand new and in-stock in the Mighty Ape warehouse. The item will ship within the timeframe shown below.

Order now and it ships tomorrow!

Note: This product cannot be shipped outside of New Zealand.

Note: This is a bulky item. Delivery to the South Island may take an extra 1-2 business days.

Availability

Mighty Fast Delivery Guaranteed

This product is In stock at Mighty Ape and ready for immediate dispatch

Delivering to:

It should arrive:

  • Tomorrow 6-9pm using Evening Express Delivery
    Mighty Ape can deliver this product in the evening between 6pm - 9pm tomorrow to qualifying addresses in Auckland. Learn more
  • Saturday using Saturday Delivery
    Mighty Ape can deliver this product on Saturday to most cities and towns in NZ. Learn more
  • Monday using standard courier delivery

Buy together and save

List price: $257.99

Buy together: $257.39 (save 0%)

15.79% of people buy Fractal Design Define R5 Mid Tower Case - Black and 140mm Fractal Design Silent Series R3 Case Fan.

Description

The Fractal Design Define R5 is the next evolution in the widely popular Define Series. Packed with intelligently designed enthusiast-oriented features delivering a silent case with powerful and expansive air and liquid cooling support, presented in a stunning Scandinavian inspired construction.

The Define R5 case reaches the highest level of silent computing through strategically placed dense sound-absorbing material, ModuVent™ fan vent covers and finely tuned Dynamic Series fans.

The Define R5 was designed with configurability in mind, accommodating up to 8 hard drives and all modern graphics card. Should you wish to expand your system with water cooling components or more fans the layout can easily be configured to meet your demand.

Specifications

  • ATX, Micro ATX, Mini ITX motherboard compatibility
  • 7 expansion slots
  • 2 – 5.25" bays (removable)
  • 8 – 3.5" HDD positions (can also accommodate 2.5" units); 2 – 2.5" dedicated SSD unit positions
  • 4 – ModuVent™ plates – three in the top and one in the side
  • 9 – fan positions (2 Fractal Design Dynamic GP14 140mm fans included)
  • Filtered fan slots in the front and bottom
  • CPU coolers up to 180mm in height
  • ATX PSUs up to 190/170 mm with a bottom 120/140mm fan installed; when not using any bottom fan location longer PSUs up to 300mm can be used
  • Graphics cards up to 310 mm in length with the top HDD cage installed; with the top cage removed, graphics cards up to 440 mm in length may be installed
  • 20 – 35 mm of space for cable routing behind the motherboard plate
  • Hook and loop straps included for easy cable management
  • Front door can switch opening direction via dual mounting system
  • Left side panel features Quick Release System for easy access and provides a secure closure of side panel
  • Right side panel features smart captive thumbscrews so no thumbscrews are lost
  • Colour: Black
  • Cooling System:
    • Front: 2 – 120/140 mm fans (included is 1 Fractal Design Dynamic GP14 fan, 1000 RPM * speed)
    • Rear: 1 – 120/140 mm fan (included is 1 Fractal Design Dynamic GP14 fan, 1000 RPM speed)
    • Top: 3 – 120/140 mm fan (not included)
    • Bottom: 2 – 120/140 mm fan (not included)
    • Side: 1 – 120/140 mm fan (not included)
    • Fan controller: 3 step fan controller for up to 3 fans
    • Dust filters: Bottom and front intakes
  • Water Cooling Compatibility:
    • Front: 360, 280, 240, 140 and 120 mm radiators of all thicknesses (requires removal of drive bays)
    • Top: 420, 360, 280, 240, 140 and 120 mm radiators. (A thickness limitation of 55mm for both radiator + fan applies on 420, 280 and 140 mm radiators) (420 and 360 mm radiators require removal of the ODD bay)
    • Bottom: 120 or 240 mm radiator (Use of radiators in the bottom position limits the PSU length to 165 mm)
    • Rear: 120 or 140 mm radiator
  • Front interface:
    • 2 USB 3.0 + 2 USB 2.0
    • Audio in/out
    • Power button with LED (blue)
    • HDD activity LED (blue)
    • Reset button

Dimensions

  • Case dimensions (WxHxD): 232 × 451 × 521mm
  • Case dimensions – with feet/screws/pro­trusions: 232 × 462 × 531mm
  • Net weight: 11.2 kg
  • Package dimensions (WxHxD): 327 × 615 × 540mm
  • Package weight: 12.8 kg

Package contents

  • Define R5 computer case
  • User manual
  • Accessory box
Release date NZ
February 25th, 2015
Manufacturer code:
FD-CA-DEF-R5-BK
Supported Motherboard Form Factor(s)
  • ATX
  • microATX
  • Mini-ITX
Maximum CPU Cooler Height (mm)
180
Maximum Water Cooling Radiator Size (mm)
240
Supported PSU Form Factor(s)
  • ATX
Maximum PCI Express Card Length (mm)
310
Number of 2.5″ Internal Drive Mounts
2
Number of 3.5″ Internal Drive Mounts
8
Number of 5.25″ External Drive Bays
2
Number of Full Length Full Height Expansion Slots
7
Front Fan 1 Size
140mm
Front Fan 2 Size
140mm
Rear Fan 1 Size
140mm
Lower Fan 1 Size
140mm
Lower Fan 2 Size
140mm
Upper Fan 1 Size
140mm
Upper Fan 2 Size
140mm
Upper Fan 3 Size
140mm
Box Dimensions (mm)
540x620x330
UPC
817301012584
Product ID
23004630
