Routers, Modems & Networking:

D-Link DES-1005D, 5 PORT 10/100 SWITCH

Sorry, this product is not currently available to order

Here are some other products you might consider...

D-Link DES-1005D, 5 PORT 10/100 SWITCH

Format

Switch

Customer rating

Click to share your rating 2 ratings (5.0/5.0 average) Thanks for your vote!

Share this product

Unavailable
Sorry, this product is not currently available to order

Customer reviews

5.0 out of 5 stars Based on 2 Customer Ratings

5 star
(2)
4 star
(0)
3 star
(0)
2 star
(0)
1 star
(0)
Write a Review
"Very cool"
5 stars"
Purchased on Mighty Ape

I like the switch as it boosts the internet going through my ps3 have ps3 running at 770kps checked it while I was playing a game of black ops 2 keep up the good work mighty apes 10/10

Description

D-Link's DES-1005D is a powerful 5 port 10/100Mbps desktop switch that is an ideal choice for small workgroups.

The DES-1005D allows users to simply plug any port to either a 10Mbps Ethernet or 100Mbps Fast Ethernet network for compatibility, convenience, and faster connection. The switch comes in a small compact size designed for easy installation and high performance. The DES-1005D eliminates unnecessary traffic and relieves data congestion by delivering dedicated bandwidth for each of the five ports.

Each port on the DES-1005D supports automatic MDI/MDIX detection providing true 'plug and play' capability without the need for confusing crossover cables or crossover ports. With the media auto-sensing feature, plug in the network cable to the DES-1005D directly without the need to worry if the end node is a NIC (Network Interface Card) or switch/hub. The DES-1005D also supports flow control and auto-negotiation of half or full duplex transfer modes for each port.

The DES-1005D provides dynamic memory allocation for data flow control to guarantee against possible packet loss. The DSS-5+ uses fast store-and-forward switching to ensure low data latency and prevents error packages from transmitting among segments.

Features:

  • (5) 10/100Mbps RJ-45 Ports
  • Auto-Senses Cable Type (Auto-MDIX)
  • Half/Full Duplex Support
  • Auto-Negotiation
  • Wire-Speed Reception and Transmission
  • 2K MAC Look-Up
  • Broadcast Storm Protection
  • Back Pressure Flow Control for Half-Duplex
  • Automatic MAC Address Learning
  • Switching Method: Store-and-Forward
  • RAM Buffer: 128Kbytes
  • Protocol: CSMA/CD
  • Complies with: 802.3 10Base-T, 802.3u 100Base-TX, 802.3x Flow Control
  • Certifications: FCC Class B, VCCI Class A, CE Mark
  • LED's: Power, Collision, Link/Act (5)
  • Dimensions: 14.2cm x 10.8cm x 3.2cm
  • Weight: 227gms
  • AC Input: 7.5V/1A , 3.6Watts (max)
  • Operating Temperature: 0°C to 50°C
  • Storage Temperature: -10°C to 70°C
  • Humidity: 10%-90% RH, non-condensing
Release date NZ
August 8th, 2005
Manufacturer code:
DES-1005D
Brand
Manufacturer
UPC
790069219900
Product ID
1473900
