PC Parts & Components:

ASUS ROG STRIX H370-I GAMING Motherboard

Customer rating

Click to share your rating 5 ratings (4.0/5.0 average) Thanks for your vote!

Share this product

$255.00
or 4 payments of $63.75 with Learn more
Hurry! Only 2 left at Mighty Ape!

The item is brand new and in-stock in the Mighty Ape warehouse. The item will ship within the timeframe shown below.

Order now and it ships tomorrow!

Availability

Mighty Fast Delivery Guaranteed

This product is In stock at Mighty Ape and ready for immediate dispatch

Delivering to:

It should arrive:

  • Tomorrow 6-9pm using Evening Express Delivery
    Mighty Ape can deliver this product in the evening between 6pm - 9pm tomorrow to qualifying addresses in Auckland. Learn more
  • Saturday using Saturday Delivery
    Mighty Ape can deliver this product on Saturday to most cities and towns in NZ. Learn more
  • Monday using standard courier delivery

Description

  • Designed exclusively for 8th generation Intel® Core™ processors to maximize connectivity and speed with dual M.2 (1× inside double-decker PCH heatsink, 1× back side), dual Gigabit LAN, onboard 802.11ac WiFi and Intel® Optane™ Memory compatibility
  • ASUS OptiMem improves memory stability and performance by improving trace isolation between PCB layers to maintain signal integrity even at higher frequencies
  • Gamer’s Guardian with Fan Xpert 4 provides hardware-level safeguards for maximum performance with dynamic system cooling
  • Aura Sync RGB lighting with additional 4-pin RGB header features a nearly endless spectrum of colors with the ability to synchronize effects across an ever-expanding ecosystem of Aura Sync enabled products
  • Pre-mounted I/O shield ensures streamlined installation and represents ROG’s attention to detail and quality

The distinctive sleek cuts across the ROG Strix heatsink are now accented with a futuristic cyber-text pattern, fusing multiple gaming cultures to create a unique identity for this generation. But it's not all about arresting looks: the all-new ROG Strix motherboards exude material excellence, with a high-quality metal heatsink that adds a premium touch.

Specs

  • CPU
    • Build in Intel® for 8th Generation Core™ Processors
    • Supports Intel® 14 nm CPU
    • Supports Intel® Turbo Boost Technology 2.0
    • The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
  • Chipset: Intel® H370
  • Memory
    • 2 x DIMM, Max. 32GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory
    • Dual Channel Memory Architecture
    • Supports Intel® Extreme Memory Profile (XMP)
    • Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
    • Hyper DIMM support is subject to the physical characteristics of individual CPUs.
    • DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.
  • Graphic
    • Integrated Graphics Processor- Intel® HD Graphics support
    • Multi-VGA output support : HDMI/DisplayPort 1.2 ports
    • Supports HDMI with max. resolution 4096 × 2160 @ 24 Hz
    • Supports DisplayPort 1.2 with max. resolution 4096 × 2304 @ 60 Hz
    • Maximum shared memory of 1024 MB (for iGPU exclusively)
  • Expansion Slots: 1 x PCIe 3.0/2.0 x16
  • Storage
    • Intel® H370 Chipset :
      • 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 × 4 mode)*
      • 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 × 4 mode)*
    • Support Raid 0, 1, 5, 10
    • Intel® Rapid Storage Technology 15 support*1
    • 4 x SATA 6Gb/s port(s),
    • Intel® Optane™ Memory Ready *2
  • LAN
    • Intel® I219V, 1 x Gigabit LAN Controller(s), Dual interconnect between the Integrated Media Access Controller (MAC) and Physical Layer (PHY)
    • Realtek® RTL8111H, 1 x Gigabit LAN
    • Anti-surge LANGuard
    • ROG GameFirst Technology
  • Wireless Data Network
    • Wi-Fi 802.11 a/b/g/n/ac
    • Supports dual band frequency 2.4/5 GHz
    • Supports MU-MIMO
  • Bluetooth: Bluetooth® 5.0*3
  • Audio
    • ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
      • Dual OP Amplifiers
      • Impedance sense for front and rear headphone outputs
      • Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
      • High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
      • Supports up to 32-Bit/192kHz playback *4
    • Audio Feature :
      • Optical S/PDIF out port(s) at back panel
      • Sonic Radar III
      • Sonic Studio III + Sonic Studio Link
  • USB Ports
    • Intel® H370 Chipset : : 2 x USB 3.1 Gen 2 port(s) (2 at back panel, , Type-A, 2 at mid-board)
    • Intel® H370 Chipset : : 6 x USB 3.1 Gen 1 port(s)
    • Intel® H370 Chipset : : 1 x USB 3.1 Gen 1 port(s)
    • ROG Exclusive Features
    • ROG RAMCache II
    • ROG CPU-Z
    • ROG CloneDrive
    • Overwolf
    • GameFirst IV
    • ROG Aura: Aura Lighting Control
  • Special Features
    • Fan Xpert4
    • Gamer's Guardian:
      • ESD Guards on LAN, Audio, KBMS and USB3.0/2.0 ports
      • DRAM Overcurrent Protection
      • Highly Durable Components
      • DIGI+ VRM
      • SafeSlot
    • ASUS EPU :: EPU
    • AURA :
      • Aura Lighting Control
      • Aura Addressable Strip Header(s)
  • ASUS Exclusive Features :
    • AI Suite 3
    • Ai Charger
    • ASUS Quiet Thermal Solution :: ASUS Fan Xpert 4 Core
    • ASUS EZ DIY :
      • ASUS CrashFree BIOS 3
      • ASUS EZ Flash 3
    • ASUS Q-Design :
      • ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
      • ASUS Q-Slot
      • ASUS Q-DIMM
    • Performance Optimization :: DIGI + VRM
  • Back I/O Ports
    • 1 x DisplayPort
    • 1 x HDMI
    • 2 x LAN (RJ45) port(s)
    • 2 x USB 3.1 Gen 2
    • 1 x USB 3.1 Gen 1 (blue) USB Type-CTM,
    • 3 x USB 3.1 Gen 1
    • 1 x Optical S/PDIF out
    • 5 x Audio jack(s)
    • 1 x Wi-Fi antenna port(s)
  • Internal I/O Ports
    • 1 x Aura Addressable Strip Header(s)
    • 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
    • 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
    • 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 × 4 mode)
    • 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 × 4 mode)
    • 4 x SATA 6Gb/s connector(s)
    • 1 x CPU Fan connector(s) (1 × 4 -pin)
    • 1 x Chassis Fan connector(s) (1 × 4 -pin)
    • 1 x AIO_PUMP connector (1 × 4 -pin)
    • 1 × 24-pin EATX Power connector(s)
    • 1 × 8-pin ATX 12V Power connector(s)
    • 1 x Front panel audio connector(s) (AAFP)
    • 1 x Internal speaker connector(s)
    • 1 x System panel(s)
    • 1 x Clear CMOS jumper(s)
  • Accessories
    • User's manual
    • M.2 2242 mounting kit
    • 2 x SATA 6Gb/s cable(s)
    • 2 x M.2 screws
    • 1 x pack of cable tie
    • 1 x Supporting DVD
    • 1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n compliant)
    • 1 x ROG Strix stickers
    • 1 x Extension Cable for RGB strips (80 cm)
    • 1 x Panel cable
  • BIOS: 1 × 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ RAID Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, ASUS DRAM SPD (Serial Presence Detect) memory information, F4 AURA ON/OFF and F9 Search, Secure Erase, User Profile.
  • Operating System: Windows® 10 64-bit
  • Form Factor
    • Mini ITX Form Factor
    • 6.7 inch x 6.7 inch ( 17 cm x 17 cm )
  • Note
    • For a 2242 storage device, use the bundled 2242 mounting kit.
    • 1 Bluetooth V5.0 will be supported on future versions of Windows. Refer to https://www.microsoft.com for updates on Windows OS Bluetooth support version.
    • 2 Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.
Release date NZ
April 4th, 2018
Manufacturer code:
ROG STRIX H370-I GAMING
Warranty Period
1 year
Brands
Manufacturer
Motherboard Form Factor(s)
  • Mini-ITX
Motherboard Main Power Connector
ATX 24-pin
Motherboard 12V Power Connector
ATX12V 8-pin
Supported CPU Socket
LGA 1151 (Socket H4) Rev.2
Supported Memory Module Type(s)
  • DIMM
Number of Memory Sockets
2
Supported Memory Type(s)
  • DDR4 SDRAM
Supported Memory Channels
  • Dual Channel
Minimum Memory Speed (MHz)
2133
Maximum Memory Speed (MHz)
2666
Maximum Memory Size (GB)
32
Number of VGA Ports
0
Number of DVI Ports
0
Number of DisplayPort Ports
1
Number of HDMI Ports
1
Number of PCI Express x16 Slots
1
Number of PCI Express x1 Slots
0
Number of M.2 Sockets
1
Number of SATA Headers
2
Number of U.2 Headers
0
Number of USB 3.0 Headers
1
Number of USB 2.0 Headers
1
Number of USB 3.0 Type-A Back Panel Ports
3
Number of USB 3.1 G2 Type-A Back Panel Ports
2
Number of USB Type-C Back Panel Ports
1
Integrated Ethernet Networking
Yes
Supported Wireless Networking Standards
  • 802.11ac
Box Dimensions (mm)
185x230x95
UPC
889349975367
Product ID
27818729
