Make premium interactive guest services available through
Samsung’s HE690 hospitality displays
Samsung’s new HE690 premium hospitality displays transform the standard hotel
TV into an all-in-one content and entertainment centre through an array of
convenient features. Through compatibility with Samsung’s LYNK REACH 4.0 IP
content management solution1, the HE690 displays enable hotel managers to
deliver customised welcome messages, promotional offers and local attraction
information to specific rooms. Additionally, guests receive access to a wider
range of entertainment options through IPTV service delivery. These benefits
make the HE690 displays the ideal addition to any hospitality setting looking to
elevate the guest experience without requiring a complete system replacement or
long-term operational disruption.
Offer personalised service from check-in through checkout
Samsung’s LYNK REACH 4.0 IP platform ensures that guests can receive
personalised attention and convenient access to on-site amenities and services
throughout the duration of their stay.
- At check-in: The LYNK REACH 4.0 IP server uses the hotel’s proprietary management server (PMS) to evaluate guests’ unique information and greet them with personalised welcome messages on the TV.
- During guest stay: Hotel managers can use data stored within the LYNK REACH 4.0 IP server to send guests personalised messages relevant to their stay, ranging from restaurant reservation portals to timing for other on-site services.
- Express checkout: LYNK REACH 4.0 IP highlights and organises all guest charges within a single screen, enabling a faster guest checkout process that does not require a trip to the lobby.
Ethernet bridge
The HE690’s design includes Ethernet bridge connectivity that is compatible
with IP devices. As a result, guests can establish a VoIP phone access point or
connect their computer to the Ethernet cable for continuous content access as
part of a multi-functional business work station. At the same time, the powerful
integrated Ethernet connection prevents hotels from having to implement separate
routers and LAN cables to guarantee full performance. Through this versatile
Ethernet bridge feature, hotels can overcome potentially weak WiFi networks and
deliver more options for guests to enjoy clear, rapidly available content.
Extend content viewing arenas through wireless device-to-display
connectivity
Samsung’s HE690 displays elevate the guest experience by serving as an
in-room, multi-device entertainment hub equipped with a host of customised
viewing features. The displays’ integrated Software Access Point (Soft AP)
functionality provides 40Mbps of wireless bandwidth supporting up to four
compatible mobile devices within a two-metre range. Once connected, guests can
transfer personal content, including music, movies and photos, from their
compatible mobile devices for viewing on the larger display screen.3,
,5 Additionally, the HE690’s screen mirroring and Digital Living Network
Alliance (DLNA)® capabilities help ensure that compatible mobile content
configures smoothly to the display without distortion or restriction.4 Guests
can also clearly view TV content on their compatible mobile devices with Smart
View TV-to-mobile transferability. The HE690’s wireless design offers guests
greater content interaction flexibility without reducing picture quality or
access parameters, giving hotels an extra edge.
System Integrator (SI) compatibility
Save time and effort when setting up multiple protocols between SI-provided
set-top boxes and displays. Samsung SMART Hospitality Displays are compatible
with various SI protocols which are available through local partnerships.
General Features
- ConnectShare™ (USB 2.0): Yes
- OSD Language: Local Languages
- Digital Clean View: Yes
- Caption (Subtitle): Yes
- Picture-In-Picture: Yes
- Auto Channel Search: Yes
- Auto Power Off: Yes
- EPG: Yes
- BT HID Built-in: Yes
- USB HID Support: Yes
- Teletext (TTX): Yes
- BD Wise Plus: N/A
- Sports/Football Mode: Basic
- Game Mode: Yes
- Analog Tuner: Yes
- Swivel (Left/Right): Yes (90/90)*
- Set Dimension with Stand (WxHxD): 730.4 × 482.8 × 192.6mm
- Set Dimension without Stand (WxHxD): 730.4 × 433.8 × 54.6mm
- Set Weight with Stand: 7.1kg
- Set Weight without Stand: 5.5kg
- Display
- Backlight: LED
- Screen Size*: 31.5"
- Resolution: 1920 × 1080
Audio
- Speaker Type: 2CH(Down Firing w/Bass Reflex)
- Sound Output (RMS): 20W(L:10W, R:10W)
Hospitality Feature
- Hospitality Home Menu: Home Menu 2015
- Samsung LYNK™ REACH: REACH4.0
- Samsung LYNK™ SINC Compatibility: Yes
- H.Browser Compatibility: Yes
- Hospitality Plug&Play (Easy Set-up): Yes
- RJ12/IR Pass Through: Yes
- Power On Mode: Yes
- USB Cloning: Yes
- Hotel Channel List: Yes
- Logo Display with Time Out Setting (BMP/Movie): Yes
- Welcome Message: Yes
- Music Mode (Input: PC/AV/Component/HDMI): Yes
- Music Mode Backlight on/off: Yes
- Auto Source Mode: Yes
- Energy Saving Mode (BLU Control): Yes
- External Clock Compatibility: Yes
- External Clock Dimming Control: Yes
- Software Clock: Yes
- My Channel: Yes
- Screwed Remote Battery Cover: Yes
- On/Off Timer (Schedule): Yes
- Security Mode: Yes
- Smoovie Compatibility: Yes
- Soundbar Compatibility: Yes
- Samsung LYNK™ DRM: Yes
- Mixed Channel List (ATSC, DVB-T/T2/C/S2, Analog): Yes
