PC Parts & Components:

120mm Noctua NF-F12 industrial - 4-Pin Fan

120x120x25mm, 3000rpm, IP52 PWM

Customer rating

Click to share your rating 5 ratings (4.8/5.0 average) Thanks for your vote!

Share this product

$39.95
Hurry! Only 2 left at Mighty Ape!

The item is brand new and in-stock in the Mighty Ape warehouse. The item will ship within the timeframe shown below.

Order now and it ships tomorrow!

Availability

Mighty Fast Delivery Guaranteed

This product is In stock at Mighty Ape and ready for immediate dispatch

Delivering to:

It should arrive:

  • Tomorrow 6-9pm using Evening Express Delivery
    Mighty Ape can deliver this product in the evening between 6pm - 9pm tomorrow to qualifying addresses in Auckland. Learn more
  • Saturday using Saturday Delivery
    Mighty Ape can deliver this product on Saturday to most cities and towns in NZ. Learn more
  • Monday using standard courier delivery

Buy together and save

List price: $57.94

Buy together: $57.49 (save 1%)

14.29% of people buy 120mm Noctua NF-F12 industrialPPC-3000 4-Pin Fan IP52 PWM and Deepcool Thermal Paste Z5.

Description

120mm Noctua NF-F12 industrialPPC-3000 4-Pin Fan IP52 PWM

Conceived for industrial heavy duty applications that require enhanced cooling performance and advanced ingress protection, the NF-F12 industrialPPC (Protected Performance Cooling) is a ruggedised high-speed version of the award-winning retail model. Thanks to the outstanding aerodynamic efficiency of the NF-F12 design and the use of a novel three-phase motor, the industrialPPC version provides superior airflow and pressure capacity while keeping noise levels and power consumption moderate as against comparable high-speed fans.

While its fibre-glass reinforced polyamide construction and certified water and dust protection make the NF-F12 industrialPPC suitable for operation in challenging environments, the renowned SSO2 bearing technology guarantees an MTBF of over 150.000hrs. Topped off with Noctua’s trusted reliability and 6 years manufacturer’s wa­rranty, the NF-F12 industrialPPC is an ideal choice for highly demanding applications that require superior flow rates and ultimate dependability.

Features:

  • Award-winning NF-F12 design
  • 3000rpm industrialPPC version
  • Three-phase motor design
  • Class-leading energy efficiency
  • Fibre-glass reinforced polyamide construction
  • Certified IP52 water- and dust protection
  • Focused Flow™ Frame
  • Varying Angular Distance and Vortex Control Notches
  • Heptaperf™ Impeller
  • AAO Frame
  • Stepped Inlet Design
  • Inner Surface Microstructures
  • Integrated Anti-Vibration Pads
  • SSO2 Bearing
  • Metal bearing shell
  • Custom designed PWM IC with SCD
  • 6 years manufacturer’s wa­rranty

Specifications:

  • Size: 120×120×25 mm
  • Connector: 4-pin PWM
  • Bearing: SSO2
  • Blade Geometry: Heptaperf™
  • Frame Technology: FocusedFlow™
  • Rotational Speed (+/- 10%): 3000 RPM
  • Min. Rotational Speed (PWM, +/-20%):750 RPM
  • Airflow: 186,7 m³/h
  • Acoustical Noise: 43,5 dB(A)
  • Static Pressure: 7,63 mm H2O
  • Max. Input Power: 3,6 W
  • Max. Input Current: 0,3 A
  • Voltage: 12 V
  • MTBF: > 150.000 h
  • Scope of Delivery: Fan, 4 Fan Screws
  • Warranty: 6 years
  • Ingress Protection: IP52
  • Material: Fibre-glass reinforced polyamide
  • Motor type: Three-phase
Release date NZ
July 28th, 2017
Manufacturer code:
NF-F12 iPPC-3000 PWM
Brand
Manufacturer
Box Dimensions (mm)
180x170x32
UPC
4716123315414
Product ID
26858581
